Bluesun Mono Solar Half Cell 375watt Pv Range 36v 360w 370w 375w Solar System for Home Use

Product Categories

Bluesun Solar Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Bluesun Mono Solar Half Cell 375watt Pv Range 36v 360w 370w 375w Solar System for Home Use

品牌 : Bluesun

型号 : BSM375M-60HPH

原产地 : Anhui, China

电池片尺寸 : 166mmx166mm

类型 : 打击乐, 半电池

尺寸 : 1755x1038x35mm

组件效率 : 20.4%

Dimensions : 1755x1038x35mm

Type : Half Cell Solar Panel

Frame : black

Brand : Bluesun

Junction Box : IP68,3/6 bypass diode

Max Series Fuse Rating : 20A

Glass : 3.2mm High Transmission Tempered Glass

Weight : 21kg

Efficiency [ : 20.4%

Front Load : 5400pa

Certificate : CE/TUV

保修期 : 25years

Contact Now

Products Description

Bluesun Mono Solar Half Cell 375watt Pv Range 36v 360w 370w 375w Solar System for Home Use

Perc Cell

The PERC cell has a passivated rear side and a laser grooving process, which significantly improves the cell efficiency.

Technical Specification

Model	BSM355M-60HPH	BSM360M-60HPH	BSM365M-60HPH	BSM370M-60HPH	BSM375M-60HPH
Max Power(Pmax) [W]	355	360	365	370	375
Open Circuit Voltage(Voc) [V]	40.5	40.7	40.9	41.1	41.3
Short Circuit Current(lsc) [A]	11.10	11.15	11.20	11.26	11.31
Max Power Voltage(Vmp) [V]	34.0	34.3	34.6	34.9	35.2
Max Power Current(lmp) [A]	10.45	10.50	10.56	10.61	10.66
Module Efficiency [%]	19.3	19.6	19.8	20.1	20.4
Power Tolerance	0-5W
Max System Voltage	DC 1500/1000(1 EC)
Max Series Fuse Rating	20A
Operating Temperature	-40 C to + 85 C
STC	Irradiance 1000W/m2, cell temperature 25C, AM 1.5

Certifications

Our Company

Bluesun Solar Co., Ltd. is a global clean energy solution service provider and high-tech photovoltaic module manufacturer. We are committed to providing one-stop energy solutions including energy supply, energy management and energy storage to customers around the world.

Feedback from our customers，if you want to know more information,please feel free to contact us,thanks!

Global Exhibition

Projects

Payment

Payment Term	T/T	EXW	30% T/T in advance, paid the balance before shipment
			30% T/T in advance, paid the balance before shipment		FOB
				CNF	30% T/T in advance, paid the balance against copy of B/L
				CIF	30% T/T in advance, paid the balance against copy of B/L
		L/C	L/C amount above 50,000 usd, we can accept L/C at sight
		West Union	Amount lower than 5000usd
Delivery Time	7~10days after receiving payment for one container
